Konbet - Teriva S-Panel ceiling system

Average grade: 0 / 0 reviews
The ceiling is especially recommended where previous generation Teriva ceilings were used, or in the case of a monolithic ceiling or other ceiling solution, the span of which does not exceed 8 meters.
On product inquiry
cennikowa cena jednostkowa netto
zł0.01
za zestaw
cennikowa cena jednostkowa brutto
zł0.01
za zestaw
promocyjna cena jednostkowa netto
zł0.01
za zestaw
promocyjna cena jednostkowa brutto
zł0.01
za zestaw
całkowita cena cennikowa netto
zł0.01
za 1 zestaw
całkowita cena cennikowa brutto
zł0.01
za 1 zestaw
całkowita cena cennikowa netto
zł0.01
za 1 zestaw
całkowita cena cennikowa brutto
zł0.01
za 1 zestaw

Products description

The ceiling is especially recommended where previous generation Teriva ceilings were used, or in the case of a monolithic ceiling or other ceiling solution, the span of which does not exceed 8 meters. This type of ceiling is used in small and large single-family houses, multi-storey apartment blocks , in twins and privates.

Features

  • low cost of the ceiling
  • saving concrete overlay
  • quick installation, as it does not require placing beams and hollow blocks between beams and numerous top reinforcement
  • no stamping up to 4 meters in the span
  • high sound insulation
  • r different bottom surface
  • the ability to hide the installation

Application

SBN prestressed concrete lintels are characterized by high functionality and easy assembly. They can be used as elements closing window and door openings in wall structures, as well as in vaults in openings in door partition walls. SBN lintels eliminate the need to pour beams, significantly accelerating the construction process.

Ring beams (shuttering blocks) are an element system in the formwork of a lowered rim. It includes elements that enable one-sided and two-sided support of the ceiling on internal and external walls (L, C or U type). The use of fittings will eliminate additional construction works related to formwork, which will facilitate and speed up the work. Due to their equal surface, they ensure even load distribution, and also improve the aesthetics of the rim.

Technical data

  • ceiling span up to 8 m
  • construction height 16, 18, 20 cm
  • panel width 60 cm
  • panel height 12 cm
  • fire resistance REI 60
  • acoustics 55.6 dB for 20 cm
  • concrete class C40 / 50
  • amount of concrete topping 62 l for 16 cm

Valuation based on the submitted project.
