Drizoro - a quick setting mortar based on Maxroad Express cement

A mixture of cement in properly selected aggregate and modifying agents. After mixing with water or mixing liquid, it forms an easy-to-apply, quick-setting cement mortar, which is characterized by high compressive strength.

Features

• good adhesion and quick bonding: the repaired area can be put into service as soon as 2 hours after application of the material at 20 C or after 1 hour at 30 C
• it can be used on damp surfaces
• breaks and disruptions in traffic caused by repairs do not exceed two hours
• resistance to freezing and thawing
• does not contain chloride
• easy to apply
• high quality and durability of the repairs performed
• high mechanical parameters

Application

• urgent repairs of floors and concrete substrates that require very quick re-commissioning, such as: airport runways, damaged as a result of wear or bombing, bridge plates, expressways, loading and unloading ramps, warehouses, parking spaces, garages, parking spaces, load-bearing capacity, access roads to the site, industrial floors, etc.
• after adding sand and aggregate up to 50% by weight as bonding material for large-volume repairs (up to 2 m)
• as a clean product for minor repairs and patching of concrete surfaces

Technical data

• appearance and color of gray powder
• specific gravity 1.36 0.10 g / cm ³
• mixing water 13-14%
• minimum application temperature of substrate and environment ˃ 5 ° C
• shelf life in 20 C and 50% relative humidity <25 min
• setting time at 20 C: Initial <30 min; final <60 min
• maturing time before putting into circulation at 20 C and 50% relative humidity 2 h
• specific gravity of the dry product after maturing 2.04 0.10 g / cm ³
• requirements for the product in repair - class R2 (unstructured) (according to EN 1504-5)
• compressive strength after 28 days 88 MPa
• bending strength: after 2.5 / 4 h - 2.2 / 2.2 MPa; after 7/28 days - 5.0 / 7.5 MPa
• ion content in chloride 0.004% (according to EN 1015-17)
• adhesion to concrete after 28 days 2.6 MPa (according to EN 1542)
• resistance to carbonation - 4 mm test concrete; 2.1 mm (according to EN 13295)
• modulus of elasticity 41.6 GPa (according to EN 13412)
• thermal compatibility: part 1 freeze-thaw 2.0 MPa (according to EN 13687-1); part 2 cyclical storm effect (thermal shock) 2.0 MPa (according to EN 13687-2); part 3 dry cycles 2.0 MPa (according to EN 13687-3)
• capillary absorption 0 kg / m ² h ^0.5 (according to EN 13057)
• fire reaction Euroclass A1 (according to EN 13501-1)
• clean product consumption 2.0 kg / m ² mm
• thickness of one layer of clean product 5-50 mm
• package 25 kg bag
